Industry

Crane & lifting equipment

Country

Germany

Software

ANSYS Mechanical

Duration

3 weeks

Crane girder FEA — static, fatigue and CE documentation

The situation

A crane manufacturer developed a new 20-tonne bridge crane girder with a modified cross-section designed to reduce material cost relative to the previous generation. Before the design could be released for production, FEM validation across all relevant load cases was required — both as an internal quality gate and to support the CE technical file. The cross-section modification introduced geometry that had not been validated in service, and the fatigue behaviour of the modified weld details needed to be assessed before any tooling was prepared.

What GFE did

GFE performed linear static analysis across all required load combinations, eigenfrequency analysis, and fatigue life calculation per FEM 1.001 crane standard. The analysis identified two weld details in the modified cross-section with stress concentrations that would not have achieved the required fatigue life. Both details were redesigned before any production tooling was cut. The revised design passed all load cases. The full analysis report was prepared in a format suitable for inclusion in the CE technical file.

Results

FEM 1.001

all load cases passed

2 welds

redesigned pre-production

~€18,000

saved vs. post-build fix

CE docs

supported

Finding those welds in simulation rather than in the field was the whole point of the exercise.

Why GFE for FEM and strength analysis

GFE works in ANSYS, Dlubal RFEM, SolidWorks Simulation, and LS-DYNA — matched to the analysis type and client environment.

GFE has resolved field failures where standard corrective measures had already been exhausted — identified through simulation.

Analysis reports are structured for CE technical files, insurance submissions, and TÜV review — not internal calculation notes.

All team members are fluent in English, with additional language skills in German, Italian, Spanish, and more.
