Industry

Hydraulics / Fluid power

Country

Austria

Software

ANSYS — coupled thermal-structural

Duration

4 weeks

Thermal FEA of hydraulic manifold — root cause found after two years of field failures

The situation

A hydraulics manufacturer had experienced repeated field failures in a manifold block under extended high-pressure operation. The failure mode was progressive seal leakage appearing after a period of continuous use at elevated load. Two rounds of material substitution had been attempted without resolving the problem. The working hypothesis before the FEA engagement was that the material was insufficiently resistant to the operating conditions — a third material change was being considered.

What GFE did

GFE ran a coupled thermal-structural analysis of the manifold block under the reported operating conditions. The analysis identified the actual failure mechanism: thermal expansion of the block under load was causing 0.12mm deformation of the seal grooves — sufficient to cause progressive leakage regardless of material. The material was not the problem. GFE proposed repositioning of the cooling bores to reduce the thermal gradient across the seal areas, validated the redesign in simulation, and the client implemented the change. No field failures have been reported since.

Results

Root cause

confirmed in simulation

0.12mm

seal groove deformation

Redesign

validated before prototype

Zero failures

after design change

We had been changing materials for two years. The problem was geometry, not material.

Why GFE for FEM and strength analysis

GFE works in ANSYS, Dlubal RFEM, SolidWorks Simulation, and LS-DYNA — matched to the analysis type and client environment.

GFE has resolved field failures where standard corrective measures had already been exhausted — identified through simulation.

Analysis reports are structured for CE technical files, insurance submissions, and TÜV review — not internal calculation notes.

All team members are fluent in English, with additional language skills in German, Italian, Spanish, and more.
