Flow simulation and structural calculations for fiber production equipment

The situation

Experimental fiber production line equipment involves both structural and flow engineering requirements that are closely interdependent. Machine frames and support structures must be validated against operating loads, while the flow behaviour of process fluids within the equipment affects both performance and structural loading. Engineering calculations using MathCad and flow simulation in SolidWorks were required as part of the broader multi-discipline design scope.

What GFE did

GFE applied SolidWorks Flow Simulation and MathCad within the existing multi-discipline engineering team, contributing to design validation of fluid dynamics and structural parameters across the fiber production equipment range. Simulation results were used directly to inform design decisions by the same team responsible for the mechanical design, allowing rapid iteration without handover delays between disciplines.

Results

Flow Sim

fluid analysis

MathCad

calculations

Integrated

in design team

5+ years

ongoing

GFE designs full-fledged 3D models and drawings in compliance with all established standards — and validates them too.

Why GFE for FEM and strength analysis

GFE works in ANSYS, Dlubal RFEM, SolidWorks Simulation, and LS-DYNA — matched to the analysis type and client environment.

GFE has resolved field failures where standard corrective measures had already been exhausted — identified through simulation.

Analysis reports are structured for CE technical files, insurance submissions, and TÜV review — not internal calculation notes.

All team members are fluent in English, with additional language skills in German, Italian, Spanish, and more.
