Industry

Machine tool / Press manufacturing

Country

Germany

Software

Pilz PNOZ · SISTEMA · EN ISO 13849

Duration

2 weeks

Safety PLC programming — PLe/Cat 4 certification for CE marking

The situation

A machine OEM needed the safety-related part of a new machine’s control system programmed to Performance Level e, Category 4, and fully documented for CE marking under the Machinery Directive. The functional safety scope included both the Pilz control programming and the complete SRP/CS documentation file required for submission to a notified body. The client’s internal team had no prior experience with functional safety programming or SISTEMA calculations, and the CE marking timeline was fixed.

What GFE did

GFE’s safety-experienced engineer handled the complete functional safety scope: Pilz PNOZ programming, SISTEMA calculation confirming PLe achieved across all safety functions, and the full SRP/CS documentation file structured for TÜV review. The documentation was submitted to the notified body and accepted without requests for revision or additional information. CE marking was granted on the original project schedule.

Results

PLe / Cat 4

achieved

TÜV passed

first submission

SISTEMA

complete documentation

CE marking

on schedule

We didn’t know how to write a safety documentation file. GFE delivered one that TÜV accepted without a single question.

Why GFE for PLC programming

Each project is staffed with engineers experienced on the relevant platform — TIA Portal, TwinCAT, Pilz, or Rockwell.

Practical experience with EN ISO 13849, SISTEMA calculations, and SRP/CS documentation for CE marking and TÜV review.

Support can be engaged for a single project or structured as a long-term team extension — without permanent hiring.

All team members are fluent in English, with additional language skills in German, Italian, Spanish, and more.

Have a PLC migration, new machine, or safety certification project?
