Industry

Precision engineering / Job shop

Country

Switzerland

Software

Siemens NX CAM · Siemens 840D

Duration

2 weeks

Post-processor development and validation for new 5-axis machining centre

The situation

A precision manufacturer installed a new 5-axis machining centre and immediately encountered a critical problem: the generic post-processor supplied with the CAM system produced unsafe output for multi-axis moves. The issues included incorrect RTCP activation sequences and unsafe retract behaviour on 5-axis trajectories. The machine could not be used for production safely. From the day of installation, the investment was generating cost without output, and the client had no internal capability to develop a machine-specific post-processor.

What GFE did

GFE developed a machine-specific post-processor for the Siemens 840D control from scratch, building it against the actual kinematics and controller behaviour of the installed machine. The post-processor was validated against 11 test geometries covering the full range of motion scenarios relevant to the client’s production — including simultaneous 5-axis moves, indexed positioning, and RTCP activation. All override options and configuration parameters were documented for the client’s own programming team to allow independent maintenance going forward. The client moved from blocked production to validated, running programs within two weeks.

Results

11 geometries

validated

Safe RTCP

correct on all 5-axis moves

Zero rework

first part within tolerance

2 weeks

blocked → production-ready

We went from blocked production to running parts in two weeks. That was crisis management.

Why GFE for CNC programming

Programs are written and validated inside the client’s own CAM environment — using their software, file structure, and naming conventions. No separate system, no format conversion.

Each project is handled by programmers with direct experience on the relevant platform — Siemens NX, SolidCAM, Mastercam, or STUDER.

All programs are collision-checked and validated in Vericut before reaching the machine. This eliminates first-part scrap and reduces setup time on the shop floor.

All team members communicate in English. Senior programmers also speak German, enabling direct coordination with production and quality departments at client facilities in DACH.
